35
2‐5MiscellaneousSettings
There are few functions provided by Edimax configuration utility, you
can access these functions from the bottom of configuration menu:
The descriptions of these function are listed as follow:
Show Tray Icon Check this box to show an icon on system
tray.
Uncheck this box to hide it.
Radio Off Switch wireless radio off. Wireless network
functionalities are disabled.
Disable Adapter Disable wireless network adapter. All
functionalities of configration menu will
disappear. To resume, unckeck ‘Disable
Adapter’.
HERE!

Other manuals for Edimax EW-7811UN

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Edimax EW-7811UN and is the answer not in the manual?

Edimax EW-7811UN Specifications

General IconGeneral
Wi-FiYes
Wi-Fi bandSingle-band (2.4 GHz)
Ethernet LANNo
Frequency range2.4 - 2.4835 GHz
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standardWi-Fi 4 (802.11n)
Security algorithms128-bit WEP, 64-bit WEP, WPA2
Networking standardsIEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Maximum data transfer rate150 Mbit/s
WLAN data transfer rates supported1, 2, 6, 9, 11, 12, 24, 36, 48, 54, 72, 150 Mbit/s
InterfaceWLAN
Connectivity technologyWireless
Chipset-
CertificationCE, FCC, WiFi
Product colorBlack, Gold
LED indicatorsActivity, Link
Storage temperature (T-T)-20 - 60 °C
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)10 - 90 %
Weight and Dimensions IconWeight and Dimensions
Depth7.1 mm
Width14.9 mm
Height18.5 mm
