Edision HDMI Modulator single DVB-T - Front Panel Overview; Front Panel Buttons; Front Panel Indicators

4
2. Connection
HDMI Signal source IN to Modulator.
Modulated RF output.
3. Front panel
1. LOCK: (DOUBLE USE BUTTON): 1.lockstheuseofthebuttons.“LOCK”led
lights up when pressed 1 time for locking. To release lock state, press again.
2.alsofunctionsas“Delete”(Space)buttonwhileeditingmenu“Name”.
