Edision HDMI Modulator single DVB-T - Operating Instructions; Parameter Setup Guide

5
2. MENU/OK:Onetimepress:“MENU”button.
Twotimespress:“Confirm”button.
3. « » Left : backward selection.
4. « » Right: forward selection.
5. « » Down: list down selection.
6. « » Up: list up selection.
4. Operating instructions
4.1 Parameters Setup
4.1.1 Output channel Setup
Press“MENU/OK”buttonandtheOLEDdisplaydisplays“Freq/CH_xx”.Press
“ “Upor“ “Downbuttontoselectthedesiredoutputchannel.Ifyoudonot
want to setup other parameters, press “MENU/OK” button and on the display
appears“Saveconfig?Yes(*)No().Press“MENU/OK”againtosavethesetting.If
youwanttosetupotherparametersalso,pleasedonotpressthisbutton.Formore
setupoptions,press“ “(Left)or“ “(Right)buttontoselectotherparameters.
Whenallyoursettingsarecomplete,press“MENU/OK”buttontwotimestosave
the settings .
