Edision HDMI Modulator Xtend - Features; Technical Specifications

4
►TECHNICAL SPECIFICATIONS
Processor
Memory
HDMI Input/Output
USB Type
Power Consumption
Video Encoder
Aspect Ratio
Resolution
Audio encoder
200MHZ 32Bits RISC
DDRII 16bit 512Mbits (Embedded) & NOR Flash 32Mbit
HDMI v1.4a
USB 2.0 HOST, Fat32 support
10W max, 100-240V AC to DC adapter 5V 2A
MPEG1, MPEG2 MP@HL, MPEG4 SP@L3 to
ASP@L5, MPEG4 AVC HP@level4.1, MP@level4.1
16:9 wide screen, 4:3 letter box, 4:3 pan scan
up to 1080p@30FPS
MPEGI L1/2, MPEGII LII, AAC LC, HE-AAC v1/v2 (2-CH)
►FEATURES
• INPUT signal: HD IN
• OUTPUT signal: Digital Terrestrial DVB-T MPEG4
• IR control over coaxial, through the embedded
EDI-Rx system.
• On board HDMI LOOP for source HDMI
signal connection to TV.
• On-board RF LOOP (IN)
• High Video Resolution up to 1080p
• Frequency Range VHF (CH. 5-12)
& UHF (CH. 21-69)
• MER more than 35dB
• Adjustable RF Output Level / Default 90dbμV
• Fast Pre-Cong Function / 50 ID’s Selectable
• Backup Cong File by USB
• Software Upgrade by USB
• Ports - Connections: HD IN, HD OUT, RF IN,
RF OUT, IR OUT, USB, DC 5V, GROUND
• 4-digit LED Display
• Front panel buttons: Button Lock, Menu/OK, Left /
Right menu selection, Up/Down menu selection.
• Low Power Consumption
