Edision HDMI Modulator Xtend - RF Specifications; IR Control System EDI-RX Specifications

5
►RF SPECIFICATIONS
Frequency Range
Impendance
RF IN
FEC
Guard Interval
Constellation
RF Output level
Bandwidth
FFT
Reed Solomon
Symbol Rate
MER
IR OUT
VHF (CH. 5-12) & UHF (CH. 21-69)
50Ω
RF signal mix through
1/2, 2/3, 3/4, 5/6, 7/8
1/4, 1/8, 1/16, 1/32
QPSK, 16QAM, 64QAM
~90dBuV Adjustable from 0 to -14dB 0 to +6d
7MHZ, 8MHZ
2K, 8K
202, 188, T=8
Up to 31.668 MBPS
>35dB at Maximum RF output level
Stereo Jack 3,5mm (Jack to IR EDI-Tx)
►IR CONTROL SYSTEM EDI-RX SPECIFICATIONS
Modulation Type
Frequency bandwidth
RF IN Input
RF OUT Output
IR Receiver OUT
DC OUT
IR Signal LED
ASK
VHF III (174-230 MHZ) & UHF (470-862 MHZ)
1x Female IEC-type
1x Male IEC-type
Stereo Jack 3,5mm (Jack to IR EDI-Rx)
5V/500mA (DC to USB cable)
IR status indication
