Edision HDMI Modulator Xtend - Page 7

DC 5V/2A
RF IN
IR OUT
HD IN HD OUT
RF OUT
1 2 3 4 5 6 7 8
Α B C D
Jack to IR Tx
cable
Jack to IR Rx
cable
7
10. Connect the power supply DC5V input of the IR Control System EDI-Rx (C) to a USB port of a TV/STB,
using the cable USB-to-DC.
11. Proceed to channel scan on your TV or STB.
