D14643880 Issue L

Installation

3.5.3 Disable set-point

The set-point can be permanently turned off by adjusting the potentiometer so that the level is < 1.8 V. This is

achieved by turning the potentiometer fully anticlockwise.

The set-point can also be used to indicate that the gauge is operating correctly by adjusting the potentiometer so

that the level is

 10 V, (potentiometer fully clockwise) - in normal operation, the set-point is switched on when the

output of the gauge is below the user adjustable trip level but above 1.8 V.

Note: If the set-point trip level is set to > 9.5 V then the set-point may not switch off when the pressure rises

since the hysteresis point will be > 10.0 V. It would then only switch off when the gauge is disabled.
