Edwards AIM-P-NW25 User Manual

© Edwards Limited 2020. All rights reserved. Page 3
Technical data
D14643880 Issue L
2 Technical data
2.1 Pressure range
2.2 Mechanical data
2.3 Materials exposed to vacuum system
Stainless steel (AISI 304), Fluoro-elastomer, Nickel (99% pure) Soda lime glass.
2.4 Operating conditions
2.5 Electronic interface
10
-8
to 10
-2
mbar (7.5 x 10
-9
to 7.5 x 10
-3
torr)
Gauge case dimensions 95 x 79 mm dia.
Overall length including flange 116 mm
Gauge tube volume 26 cm
3
Weight AIM-P 810 g
Weight AIM-PL 860 g
Maximum internal pressure 10 bar absolute (9 bar gauge)
Temperature range +5 °C to +60 °C
Relative humidity (non condensing) 10 -90%
Maximum operating altitude 2000 m (indoor use only)
Pollution degree 2
Enclosure rating
*
*
Complete gauge attached to vacuum system.
IP40 and IP403
Socket connection (See Appendix A1) FCC68/RJ45 Type, 8 way
