Maintenance
5.4 Fault finding
The gauge has integral error monitoring features as described in Section 4.2. These features monitor the gauge signal
output for out of range and gauge strike errors. When an error is detected the set-point is turned off
(see Section 4.2).
The user should check for correct connections (Section 4) and ensure that the power supply voltage is in the range
13.5 - 36 Vd.c. positive and that pin 7 is connected to 0 V (see Figure 2).
