Edwards GXS 750/2600

Figure 2 Front view of the pumping system with the side exhaust and skids ed
1
2
6
5
4
3
CS/1060/A
1. Front panel controls 2. Floor mounng plate (4 o)
3. Exhaust gas outlet connecon 4. Liing eyebolts (4 o)
5. Pumped gas inlet connecon 6. RF earth (ground) cable
1. Front panel controls 2. Floor mounng plate (4 o)
3. Exhaust gas outlet connecon 4. Liing eyebolts (4 o)
5. Pumped gas inlet connecon 6. RF earth (ground) cable
Page 13
M58800880_H - Introducon
