Edwards GXS 750/2600

Figure 7 The Harng Han® K 4/4 cable-mounted connector
1. Low volt pin conguraon 2. High volt pin conguraon1. Low volt pin conguraon 2. High volt pin conguraon
A. Mounng screw B. Coding pin
C. Insert stranded wire D. 2.5 mm hex (allen) key
A. Mounng screw B. Coding pin
C. Insert stranded wire D. 2.5 mm hex (allen) key
Pin idencaon
Pin 1 Phase 1
Pin 2 Phase 2
Pin 3 Phase 3
Pin 4 Not connected
PE Protecve earth
Torque sengs for connector pins
Cable size (mm
2
)
Maximum torque seng (Nm)
6 2
10 3
16 4
Page 42
M58800880_H - Installaon
