A735-01-880 Issue C
Page 42 © Edwards Limited 2017. All rights reserved.
Edwards and the Edwards logo are trademarks of Edwards Limited.
Spares and accessories
7.2.6 Exhaust nozzle
The exhaust nozzle screws into the outlet flange. Use the exhaust nozzle to connect the pump to the 12 mm internal
diameter plastic hose.
7.2.7 Chemical resistance conversion kit
This adaptor kit allows a standard nXDS pump to be converted into an nXDS-C version. This conversion may be
necessary if the pump is used on applications involving corrosive substances. For more information, contact Edwards.
Note: If returning the pump to Edwards for repair or service having been converted from a standard version to
an nXDS-C version, Edwards service must be informed, otherwise the pump will be returned back as a
standard version.
7.2.8 Electrical cables
Refer to Table 23. The following electrical cables are available as accessories and should be used to connect the nXDS
pump to the electrical supply.
s
7.2.9 Pump-to-controller cable
Use the control cable to control the nXDS pump using an Edwards Turbo Instrument Controller (TIC) or TIC Turbo
Controller, or a (TAG) Active Gauge controller.
Table 21 - Exhaust nozzle
Product description Ordering information
Exhaust nozzle A505-09-000
Table 22 - Chemical resistance conversion kit
Product description Ordering information
Chemical adaptor kit for nXDS 6i, 10i or 15i A735-01-807
Chemical adaptor kit for nXDS20i A735-01-808
Table 23 - Electrical cables
Product description Ordering information
Lead Assembly, 10 A, C13, UK A505-05-000
Lead Assembly, 10 A, C13, Europe A505-06-000
Lead Assembly, 10 A, C13, USA A505-07-000
Lead Assembly, 10 A, C13, No Plug A505-08-000
Table 24 - Pump-to-controller cables
Product description Ordering information
1 m cable D395-00-835
2 m cable D395-00-836
5 m cable D395-00-837
