INSTALLATION OF THE STP PUMP
2
2.1.2 Installation area
Leave enough space for the following in addition to that for the STP pump:
• Space for maintenance and inspection.
• Space for connecting cables.
CAUTION
The minimum bending radius of the STP connection cable is 200 mm (STP-301/451/L301/L451
series: 160 mm) (see the STP Pump Instruction Manual (B), "External Appearance of the STP
pump" [bending dimensions of the connection cable]).
DO NOT bend the cables excessively and beware of any obstacles when installing the STP pump.
In addition, leave enough space to install other cables without bending them excessively.
Note: The L-type STP connection cable is also offered. Contact Edwards if necessary.
