Edwards STP-XF813 Series

STP Series Turbomolecular Pump
MT-00E-1C1-D
Page 56
SERVICE, SPARES AND ACCESSORIES
8
8.4 Accessories
The following is a list of accessories that can be purchased by contacting Edwards.
Items
Application purpose
Remarks
Instruction Manual (A)
*1
Generic Instruction Manual
This manual
Instruction Manual (B)
*1
Pump Specific Information
Instruction Manual (C)
*1
Control unit Instruction Manual
applicable to your STP pump
Instruction Manual (D)
*1
For STC-U eTMS unit
STP control unit
For control the STP pump
Refer to the STP Pump
Instruction Manual (B) for the
applicable STP control unit.
Power cable
*2
Primary input power
No shielded cable.
Standard cable length is 5 m.
Contact Edwards for further
information.
Power extension cable
*2
Power extension cable which supplies
power from STC-U to STP control unit
STP connection cable
*2
Connection cable between the STP
pump and the STP control unit
Standard cable length is 5m.
Contact Edwards for further
information.
TMS heater cable
*2
Connection cable between STC-U and
TMS heater of STP pump
Shielded cable.
Standard cable length is 5 m.
Contact Edwards for further
information. The cable type
varies depending on STP pump
to be connected. Refer to
Instruction Manual (B).
TMS sensor cable
*2
Connection cable between STC-U and
temperature sensor of STP pump
TMS valve
*2
TMS valve controls the cooling water
in order to maintain a constant
temperature inside the STP pump
STC-U remote cable
*2
Connection cable between STC-U and
STP control unit
Shielded cable.
Standard cable length is 5 m.
Contact Edwards for further
information.
Outlet port heater cable
*2
*1
STP pump consists of the four-volumed Instruction Manuals.
*2
Optional accessory
