Technical data
A732-01-880 Issue D
2.4 Electrical data
2.4.1 Electrical cables
Recommended cordsets and fuses for regional requirements.
Table 4 - Electrical ratings for continuous operation
Pump Supply (V) Phase Frequency (Hz) Current (A)
XDS100B
200-230 Single 50/60 6.6
100-120 Single 50/60 10.6
Table 5 - Recommended regional supply protection
Area Voltage Rating
UK 230 V 13 A
Europe 230 V 16 A
US 120 V 15 A
Japan 100 V 15 A
Table 6 - Recommended cordsets
Description Rating Coupler type Item number
Cordset assembly, UK
Cable style = H05VV-F, 3 x 1.5 mm
2
, 300 V,
70°C, maximum length of 2.5 metres
Straight entry A50505003
Plug type = BS1363 UK plug
Appliance coupler = IEC60320 style C19
Right angled
entry
A50505006
Fuse type = BS1362 13 amp fuse, to an
IEC60320 style
Cordset assembly, Europe
Cable style = H05VV-F, 3 x 1.5 mm
2
, 300 V,
70°C, maximum length of 2.5 metres
Straight entry A50506003
Plug type = European Schuko VDE approved,
16 A, 250 V rated with dual earthing contact
Appliance coupler = IEC60320 style C19 Right angled
entry
A50506006
Cordset assembly,
USA/Canada (200-230 V)
Cable style = SJT, 3 x 14 AWG, 300 V, 90 °C,
VW-1 maximum length of 3 metres
N/A
Plug type = NEMA, 6-15P plug
Appliance coupler = IEC60320 style C19
