22
Optional FUSIBLE Disconnect Switch
DISCONNECT SWITCH MODEL 200 AMP 100 AMP
RATING (A) 200 A 100A
OPERATING VOLTAGE 600 V 600 V
Max horsepower rating/ Max motor FLA current
Three phase
208 V 50/150 25/78.5
240 V 60/154 30/80
480 V 125/156 60/77
600 V 150/144 75/77
DC 125 V (2 pole in series) 15/112 7.5/58
DC 250 V (3 pole in series) 40/140 20/38
Short circuit rating with fuses 200 200
Branch circuit fuse type J J
Max fuse rating (A) 200 100
Nema Type: 4, 4X IEC TYPE: IP65 Color: Red/Yellow
DISCONNECT HANDLE
