MINIMUM - 8” CLEARANCE ABOVE UNIT
3
Figure 1
MOUNTING
HOLES
To independent
circuit breaker
serial #
LUG
TERMINALS
AT RELAYS
ELECTRICAL
HOOK-UP
240V/208V
L1 L2 L1 L2
GROUND
LUG
Factory installed jumpers from
L1 –L1 and L2 – L2
