EemaX EX160 TC User Manual

Inlet isolating valve-
ball valve. (Always leave fully
open when unit is in service.)
MINIMUM - 8” CLEARANCE ABOVE UNIT
L N L
N
RELAY LUGS
ELECTRICAL
HOOK-UP
240/208 V
Outlet isolating valve-
ball valve (leave open
just enough to obtain
adequate flow of hot water)
Figure 1
3
4”
MOUNTING
HOLES
Two independent circuit breakers
L 1 L2 L1 L2
RELAY LUGS
ELECTRICAL
HOOK-UP
277 V
ground
10 ½’’
10’’
