MINIMUM - 8” CLEARANCE ABOVE UNIT
4
Figure 1A
MOUNTING
HOLES
To 4 Independent
circuit breakers
serial #
LUG
TERMINALS
AT RELAYS
ELECTRICAL
HOOK-UP
220/240 V
L1 L2
C/B #2
L1 L2
C/B #3
L1 L2
C/B #4
L1 L2
C/B #1
GROUND
LUGS
