EemaX FlowCo SPEX80 - Installation Procedures; Mounting the Unit to the Wall

4
1) MOUNTING THE UNIT TO THE WALL
THIS HEATER MUST BE INSTALLED IN A LOCATION WHERE IT IS NOT SUBJECT TO
FREEZING TEMPERATURES.
1. The heater should be mounted on the wall under the sink, as close to the point-of-use as possible. Ideal
position is fittings pointed down, but the heater can be mounted in any orientation.
2. Make sure to leave a minimum of 8 inches service
clearance at the end OPPOSITE the fittings.
3. Remove the cover and fasten to the wall using the
four mounting holes at each corner of the back plate.
Replace the cover.
