9
1. Power cable entry to the heater should be made
through one of the knock-out holes located on the
back plate or top/bottom ends of the unit. Use the
appropriate strain relief fitting.
2. The power leads are to be secured to the L1 and
L2 or L and N connectors on the terminal block or
relay. The ground lead is to be secured to the GND
connector on the block or the green ground wire
with the provided wire nut.
FAILURE TO GROUND THE SYSTEM MAY RESULT IN SERIOUS INJURY, DEATH AND/OR
PROPERTY DAMAGE.
3. Leave the breaker in the “OFF” position. Proceed
to the next section:
COMMISSIONING THE HEATER
