EFA 66 - List of Spare and Wear Parts

Schmid & Wezel
D 75433 Maulbronn
Page
12/ 22
Version
02.2009
A.3 List of spare and wear parts
EFA 66
Fig. Pcs. Designation Order No.
1 Brisket saw 42V 50Hz 110 885 650
1 Brisket saw 42V 60Hz 110 885 654
1 Brisket saw 115V 50Hz 110 885 652
1 Brisket saw 200V 50Hz 110 885 665
1 Brisket saw 200- 240V 60Hz 110 885 655
1 Brisket saw 230/400V 110 885 660
1 1 42V: Rubber hose line 001 601 760
1 115...400V: Rubber hose line 001 601 711
2 1 42V: Cable screw connection 001 325 531
1 115…400V: Cable screw
connection
001 325 529
3 4 Hexagon screw 001 325 905
4 4 Spring lock washer 001 317 007
5 1 42V: Cover 003 010 522
115V…400V: Cover 003 009 798
6 1 Seal 003 009 799
7 1 Breaker 001 601 206
8 1 Cover cap 003 002 454
9 4 Slotted pan head screw 001 326 101
10 4 Spring lock washer 001 317 007
11 1 Washer 003 009 855
12 3 Hexagon socket flat head screw 001 326 509
13 1 Seal 003 008 244
14 1 Parallel pin 001 307 225
15 1 Housing, complete 008 011 149
16 2 Parallel pin 001 307 223
17 1 Switch lever 003 010 817
18 1 Bail 003 009 801
19 2 Gasket ring 001 313 105
21 2 Hexagon socket pan head screw 001 326 016
21 1 Blind plug without o-ring 001 368 640
22 1 115…400V: Earthing clamp 001 605 601
23 1 115...400V: Spring lock washer 001 317 007
24 1 115...400V: Slotted pan head
screw
001 326 101
25 1 42V: Clamp 001 605 006
26 1 Bracket, complete 007 009 802
27 2
O-ring 001 312 605
28 1 Bolt 003 009 817
29 1 Swivel fixture 001 607 164
30 1 Screw in fitting (straight) with
sealing washer
001 607 165
31 2 Gasket ring 001 313 102
