EFA 66 - Page 37

Schmid & Wezel
D 75433 Maulbronn
Page
13/ 22
Version
02.2009
Fig. Pcs. Designation Order No.
32 1 Ball valve 001 362 005
33 1 Gasket ring 001 313 102
34 1 External thread sleeve 001 366 205
35 1 Spring lock washer 001 317 004
36 1 Hexagon nut 001 300 244
37 1 Screw fitting (straight) 001 607 151
38 1 Water tube 007 009 882
39 1 Handle 003 011 150
40 1 Spring washer 001 314 604
41 2 Deep groove ball bearing 001 345 316
42 1 Armature axle, complete 007 011 354
43 1 Key 001 305 444
44 1 42V 50Hz: Stator housing,
complete
008 011 355
1 42V 60Hz: Stator housing,
complete
008 012 021
1 115V 50Hz: Stator housing,
complete
008 011 356
1 210V 50Hz, 210-240V 60Hz:
Stator housing, complete
008 011 357
1 230/400V 50Hz: Stator housing,
complete
008 011 358
45 2 Hexagon screw 001 325 915
46 1 Housing 003 009 809
47 1 Seal 003 009 810
48 4 Washer 001 313 105
49 1 Ring 003 002 939
50 4 Hexagon socket pan head screw 001 326 038
51 8 Slotted flat head screw 001 326 406
52 2 Cover 003 009 940
53 4 V-ring, Seeger 001 317 125
54 2 Sleeve 003 009 941
55 2 Connecting rod 003 009 811
56 2 Deep groove ball bearing 001 340 656
57 1 Eccentric tappet 003 009 939
58 1 Washer 003 009 852
59 1 Hexagon socket flat head screw 001 326 506
60 1 Bolt 003 009 942
61 3 Sintered bearing 002 000 319
62 4 Plate 003 010 046
63 1 Guide, complete 007 009 944
64 1 Spring pin 001 308 121
65 1 Bracket 003 009 946
66 8 Spring lock washer 001 317 002
67 8 Hexagon screw 001 325 912
68 1 O-ring 001 317 738
69 1 O-ring 001 317 740
70 1 Rod seal (without o-ring) 001 607 163
