EFA 66 - Page 38

Schmid & Wezel
D 75433 Maulbronn
Page
14/ 22
Version
02.2009
Fig. Pcs. Designation Order No.
71 1 Ring 003 010 045
72 1 Spindle 003 009 945
73 1 Bolt 003 009 813
74 2 Sintered bearing 002 000 325
75 1 Guide 003 009 943
76 2 Sleeve 003 009 948
77 1 Housing 003 009 816
78 16 Gasket ring 001 313 105
79 8 Hexagon screw 001 325 908
80 8 Hexagon screw 001 327 202
81 1 Sawblade 007 009 819
82 2 Special hexagon screw 002 000 221
83 1 Bracket, complete 007 009 858
84 1 Guide 003 009 806
85 3 Spring lock washer 001 317 003
86 3 Hexagon screw 001 325 908
Special accessories
without
Fig.
Spring balancer 20-30kp 001 620 052
Transformer 42V 3kVA 001 604 507
Relay switch 42v 001 604 101
Sawblade T=9 Z=29 007 009 860
