CONTROLS and CONNECTIONS
Cover screw
Air output
quick-connect
Power
switch
2
1
Air pressure
regulator
3
4
Timer bypass
5
Time
controlAir gauge
Cycle
LED
220
Air input
Solenoid Power input
receptacle
Foot pedal
receptacle
Voltage selector
and fuse cartridge
