We have organized this Guide to provide setup and testing proce-
dures for the 1000XL and 1000D dispensers.
If you have the 1000XL, first review pages 6 - 9 which illustrate how
to hook up the dispenser and what the controls do.
For the 1000D, review pages 10 - 13.
Next, pages 14 - 15 show how to dispense the thick, paste-like test
material included in the Test Kit. These instructions are common to
both 1000 Series dispensers.
Finally, pages 18 - 19 illustrate how to dispense low-viscosity liquid
using the vacuum control provided on the 1000XL.
The rest of the information in this Guide applies to both of the 1000
Series dispensers.
1000 Series Specifications
Input voltage: Selectable
100/120/220 VAC
50/60 Hz 16/13 VA
Internal voltage: 24 VDC
Foot-pedal voltage: 9 VDC
Air input: 80 to 100 psi
(5.5 to 6.9 bar)
Air output: 0 to 100 psi
(0 to 6.9 bar)
Cycle rate: > 600/minute
Time repeat: ±0.1%
Initiation: maintained or momentary
Time Range: programmable (seconds)
0.005 to 0.04 sec.
0.01 to 1.0 sec.
0.1 to 10 sec.
0.2 to 20 sec.
0.3 to 31 sec.
1000XL
10⅜ x 8½ x 2⅝ 5 lb 12 oz
26.4 x 21.6 x 6.7 cm 2.63 kg
1000D
8⅝ x 8½ x 2⅝ 4 lb 12 oz
21.9 x 21.6 x 6.7 cm 2.18 kg
