CONTROLS and CONNECTIONS
5
4
Voltage selector and
fuse cartridge
Air input
Vacuum transducer
air exhaust port
Cover screw
Power input
receptacle
Barrel
vacuum control
Vacuum gauge
Air output
quick-connect
Power
switch
2
1
Air pressure
regulator
3
6
Timer
bypass
7
Time
controlAir gauge
Cycle LED
