In general
The Boiler
Effecta 222 is a boiler which is to be fueled with wood pellets. No other kind of fuel is allowed to
be used. Not logs or oil.
Disassembly and disposal
It will be many years before your Effecta boiler is worn out, but it is important that you follow the
regulations in force at the time concerning disassembly and disposal of your boiler.
The fuel
The boiler should normally burn 6/8 mm pellets which come either in 16 kg sacks or are supplied
by bulk truck. If you have built a bulk storage, you should follow the current recommendations to
ensure that the quality of the pellets does not deteriorate. Never use pellets which do not meet
European pellet standards, as this may result in problems in operating the burner.
▀
Symbols in the manual
Information
This symbol is shown with info to the installer which can be important to know and understand.
Neglecting these informations can affect the performance of the product.
Dangerous electricity
This symbol means that extra caution should be taken. Otherwise serious personal injury
might occur. When maintaining the product where this symbol is present the power must be
disonnected. All electrical wiring must be done by a proffesional.
This product manual is a living document. You will always find the latest verion on our
webpage, www.effecta.se
▀
Type plate
2012 2012 2013 2014 2015
Tillverknings år. / Manufacturing year
Tillverkare / Manufactory
Hersteller / Fabricants
Modell / Model
Typ / Modéle
Max drifttemp. / Max temp. (C)
Max. Betriebstemp. / Temp d’opération max
Effekt / Heat output
Heizleistung /Puissance nominale (kW)
Elinstallation / Electrical supply
Strom / Branchement électrique (VAC)
El-patron / Electrical heater (kW)
El-Patrone / El-cartouche
Vattenvolym / Water volume
Wasserinhalt / Contenance d`eau (litre)
Tillverknings nr / Manufacturing number
Herstell Nr / Numéro de fabrication
Effecta Energy Solutions AB
Effecta 222
100
20
230/380~50Hz
2 /6 / 9
205
Effecta AB - Sweden - Kungsbacka - www.effecta.se
Max drifttryck / Max pressure
Max Betriebsdruck / Pression maximum (bar)
1,5
Tillverknings månad / Manufacturing month
1 2 3 4 5 6 7 8 9 10 11 12
Godkänd enl. / Approved by
Zugelassen nach / Approuvé á
EN-303-5
The type is placed on the top of the boiler. Here you can see
production number, month and year.
