9
Front Top Back
1 Adjustable feet 1 Smoke connection 1 Drain
2 Soot door 2 Cable gland 2 Return hotwater
3 Microswitch (inside the door) 3 Valve combination 3 Cable gland
4 Handle 4 Shuntvalve
5 Hole for burner 5 Lid
6 Control panel 6 Expansion / hotwater
7 Power for burner* 7 Hole for measuring instrument
8 Flame sensor*
9 Power for auger*
▀
Placement of the components
*Only with Effecta Supra/Aero.
