UPS MKD2000/3000 Manual
8.3 Connecting the UPS with the Battery
The UPS and the Battery safely switched off beforehand.
Please, only the provided battery cables use.
Please check, the voltage from the UPS and the Battery.
Fig. 7:
Connection the
UPS and the
Battery.
8.4 Connection sequence
Connect the UPS to the mains making sure that the mains and UPS are safely
switched-off beforehand.
Connect the UPS with the battery
Before connecting the consumer with the output, the basic configuration (9.2.3)
has to be made.
Connect the consumer load(s) to the UPS. Ensure that all consumer loads are
switched off.
