UPS MKD2000/3000 XL Manual
MKD XL Series
Page 13 of 45
6 Description of MKD series
In this chapter you will be confronted with the corresponding machine
elements, get instructions for the handling and get information concerning the
connectings of the UPS.
6.1 Handling elements on the front side
Fig.. 2:
display
MKD series
All handling and display elements, which are necessary for normal service, are
on the front side.
1
7
4
3
6
5
2
