Device Description of UPS
MTD Series
21
1 LCD display
2 LED display "FAULT"
3 LED display "WARNING"
4 LED display "NORMAL"
5 Key "LCD"
6 Key "POWER ON/OFF"
Fig. 3-1 - 2 Front view of MTD 1000RM, 1500RM
1 LED display "FAULT"
2 LED display "WARNING"
3 LCD display
4 LED display "NORMAL"
5 Key "Menu selection"
6 Key "Menu decrease"
7 Key "Menu increase"
Fig. 3-1 - 3 Front view of MTD 2000RM
