Electronic device DMU2000 - DMU3000 - DMU3000 PLUS
18
Electronic device DMU2000 - DMU3000 - DMU3000 PLUS
16 Winch maximum capacity ( maximum weight )
A value expressed in kg appears next to this indication: this is an indication of the weight on the
hook which should not be exceeded when using the winch. Otherwise all crane boom lifting move-
ments and winch lifting movements are automatically stopped.
In order to use this function the optional “radio pin” or “winch proportional load cell” must be fitted to
the crane. Please note that the value of weight which appears next to this indication is relating to the
use of the winch in one-cable lifting configuration (direct pull).
17 Detecting winch load with load cell ( enverr )
Depending on the type of crane, and the type of winch fitted, it may happen that instead of the
traditional “torque limit”, a proportional load cell is fitted to the same winch to limit the maximum ca-
pacity of the load applied to the hook. In these specific cases, you get crane good operation if ON ap-
pears next to such indication.
If off appears the crane is inoperative.
18 Detecting pin load on winch (enperno)
Depending on the type of crane, and the type of winch fitted, it may happen that instead of the tradi-
tional “torque limit” a proportional load cell is fitted to the hook connecting pin to limit the maximum
capacity of the load applied to the hook . In these specific cases, you have the good operation of the
crane if ON appears next to the indication.
If off appears the crane is inoperative.
19 Enabling load reading with radio pin on winch or hook ( enpeso )
The cranes which are not provided with the function described in paragraph 17 or 18 a pin for the
junction of the hook to the crane can be installed - always as an option - with a proportional load cell
at its interior, with which it is possible to have an indication of the value of the load applied to the hook.
This value can be read on the display of the radio pushbutton panel. To use this function, ON should
appear next to the indication.
Off disables the function.
