QS Series Basic Operator's Guide
4 Dispose of the old waste tank and its contents in a
manner consistent with your local safety and
environmental regulations.
5 Ensure the waste tank’s vent hole cap is removed and the
hole is open.
6 Insert the float switch assembly into the new waste tank
and screw the cap on.
Cleaning the static eliminator bars
In order for the static eliminator bars to operate at optimum
efficiency, they must be cleaned on a monthly basis to remove
dust and debris. The static eliminators may need to be
cleaned more regularly, depending upon the operating
environment and types of media used.
1. From the VUTEk User Interface Service menu, click
Service Aids. From the Service Aids dialog box
Carriage Maintenance Positions section, click
Maintenance to move the carriage to the maintenance
position.
2. Turn off the UV lamp system.
In the UV Lamp Control Diagnostics dialog box, click
Stop Lamps ( ).
3. Turn off the static bar power supply located at the back
and on top of the carriage.
The switch lights up red when it is on.
4. Using a small brass bristled brush, lightly brush along
the slot containing the sharp pins (underneath the bar),
until the slot and the pins are free from dust and dirt.
5. Vacuum the slot to remove any remaining debris.
6. Use an inspection mirror to inspect the pins, they should
be sharply pointed and free of debris.
7. Repeat steps 3 through 6 for the static bar on second lamp
housing.
OMM-00038-US English-F 53
