4.5 Installing the fuel cartridge holder
1. Supply air
2. Exhaust air
3. Connections
Fuel cartridges and reserve fuel car-
tridges must not be placed in front of
the inlet or outlet for the off-heat flow.
Do not place any other objects in front
of the inlet or outlet for the off-heat
flow.
Observe the instructions for positioning
the fuel cartridge on page 21.
Secure the fuel cartridge holder with
four screws and, if necessary, with
dowels to ensure that it will remain in
place even if significant force is applied
to it, for example, in the event of an ac-
cident.
