EINHELL TC-CS 1410 User Manual

GB
- 31 -
Danger!
The equipment and packaging material are
not toys. Do not let children play with plastic
bags, foils or small parts. There is a danger of
swallowing or suocating!
•
Hand-held Circular Saw
•
Saw blade
•
Saw blade wrench
•
Parallel stop
•
Original operating instructions
3. Proper use
The hand-held circular saw is designed for sa-
wing straight cuts in wood, wood-type materials
and plastics. When working, be careful not to
overheat the tips of the saw blade and melt the
plastic.
The equipment is to be used only for its prescri-
bed purpose. Any other use is deemed to be a
case of misuse. The user / operator and not the
manufacturer will be liable for any damage or inju-
ries of any kind caused as a result of this.
Please note that our equipment has not been de-
signed for use in commercial, trade or industrial
applications. Our warranty will be voided if the
machine is used in commercial, trade or industrial
businesses or for equivalent purposes.
4. Technical data
Sound and vibration
Sound and vibration values were measured in
accordance with EN 62841.
Wear ear-mus.
The impact of noise can cause damage to hea-
ring.
Keep the noise emissions and vibrations to a
minimum.
•
Only use appliances which are in perfect wor-
king order.
•
Service and clean the appliance regularly.
•
Adapt your working style to suit the appliance.
•
Do not overload the appliance.
•
Have the appliance serviced whenever ne-
cessary.
•
Switch the appliance off when it is not in use.
Caution!
Residual risks
Even if you use this electric power tool in
accordance with instructions, certain resi-
dual risks cannot be rules out. The following
hazards may arise in connection with the
equipment’s construction and layout:
1. Lung damage if no suitable protective dust
mask is used.
2. Damage to hearing if no suitable ear protec-
tion is used.
3. Health damage caused by hand-arm vib-
rations if the equipment is used over a pro-
longed period or is not properly guided and
maintained.
5. Before starting the equipment
Before you connect the equipment to the mains
supply make sure that the data on the rating plate
are identical to the mains data.
Warning!
Always pull the power plug before making
adjustments to the equipment.
5.1 Setting the cutting depth (Fig. 2/3)
•
Undo the locking screw for setting the cutting
depth (4).
•
Place the soleplate (6) flat on the surface of
the workpiece you wish to saw. Raise the saw
until the saw blade (12) is at the required cut-
ting depth (a).
•
Refasten the locking screw for setting the
cutting depth (4). Check that everything is
securely fastened.
5.2 Miter stop (Figure 4/5)
•
The preset standard angle between the saw
foot (6) and saw blade (12) is 90°. You can
adjust this angle to carry out angled cuts.
•
Release the locking lever for miter setting (7)
on the front of the saw foot.
•
You can now adjust the cutting angle to
around 45°. Keep an eye on the cutting angle
scale (9) as you do so.
•
Refasten the locking lever for miter setting (7).
Check the handle is securely fastened.
5.3 Extraction of dust and chips (Figure 6)
•
Connect a suitable vacuum cleaner to the
provided chip extractor connector (14) of your
Anl_SA_TC_CS_1410_SPK8.indb 31Anl_SA_TC_CS_1410_SPK8.indb 31 02.12.2021 15:27:0902.12.2021 15:27:09

EINHELL TC-CS 1410 Specifications

General

Dust blower	Yes
Product color	Red
Built-in light	No
Suitable for materials	Wood
Blade diameter	190 mm
Number of teeth	24
Idle speed (max)	5500 RPM
Cutting depth (45º)	46 mm
Cutting depth (90º)	67 mm
Input power	1410 W
Power source	AC
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz

Weight and Dimensions

Weight	4330 g
Package depth	270 mm
Package width	360 mm
Package height	290 mm
Package weight	5450 g
