machine is used in commercial, trade or industrial
businesses or for equivalent purposes.
4. Technical data
Mains voltage: ............................... 230 V ~ 50 Hz
Power input: ............................................ 1500 W
Idling speed: ........................................5500 min
-1
Cutting depth at 90°: ................................ 66 mm
Cutting depth at 45°: ................................ 48 mm
Saw blade: ..........................................Ø 190 mm
Blade holder: .........................................Ø 30 mm
Blade thickness: ...................................... 2.8 mm
Protection class: ............................................ II/
쓑
Weight: .......................................................5.2 kg
Danger!
Sound and vibration
Sound and vibration values were measured in
accordance with EN 60745.
L
pA
sound pressure level ..................... 90.2 dB(A)
K
pA
uncertainty .............................................3 dB
L
WA
sound power level ..................... 101.2 dB(A)
K
WA
uncertainty .............................................3 dB
Wear ear-muff s.
The impact of noise can cause damage to hea-
ring.
Total vibration values (vector sum of three direc-
tions) determined in accordance with EN 60745.
Handle
Vibration emission value a
h
 2.5 m/s
2
K uncertainty = 1.5 m/s
2
Additional handle
Vibration emission value a
h
= 2.664 m/s
2
K uncertainty = 1.5 m/s
2
The specifi ed vibration value was established in
accordance with a standardized testing method. It
may change according to how the electric equip-
ment is used and may exceed the specifi ed value
in exceptional circumstances.
The specifi ed vibration value can be used to
compare the equipment with other electric power
tools.
The specifi ed vibration value can be used for initi-
al assessment of a harmful e ect.
Keep the noise emissions and vibrations to a
minimum.
•
Only use appliances which are in perfect wor-
king order.
•
Service and clean the appliance regularly.
•
Adapt your working style to suit the appliance.
•
Do not overload the appliance.
•
Have the appliance serviced whenever ne-
cessary.
•
Switch the appliance off when it is not in use.
•
Wear protective gloves.
Caution!
Residual risks
Even if you use this electric power tool in
accordance with instructions, certain resi-
dual risks cannot be rules out. The following
hazards may arise in connection with the
equipment’s construction and layout:
1. Lung damage if no suitable protective dust
mask is used.
2. Damage to hearing if no suitable ear protec-
tion is used.
3. Health damage caused by hand-arm vib-
rations if the equipment is used over a pro-
longed period or is not properly guided and
maintained.
5. Before starting the equipment
Before you connect the equipment to the mains
supply make sure that the data on the rating plate
are identical to the mains data.
Warning!
Always pull the power plug before making
adjustments to the equipment.
5.1 Setting the cutting depth (Figure 2/3)
•
Release the handle on the rear of the guard
hood for adjusting the cutting depth (4).
•
Place the saw foot (6) flat on the surface of
the workpiece you wish to saw. Raise the saw
until the saw blade (12) is at the required cut-
ting depth (a).
•
Refasten the handle for adjusting the cutting
depth (4). Check the handle is securely faste-
ned.
Anl_TE_CS_190_Kit_SPK7.indb 21Anl_TE_CS_190_Kit_SPK7.indb 21 23.02.16 16:5323.02.16 16:53

EINHELL TE-CS 190 Specifications

General

Soft start	Yes
Product color	Grey, Red
Built-in light	No
Suitable for materials	Particle board, Plastic, Wood
Blade bore	30 mm
Blade diameter	190 mm
Number of teeth	24
Idle speed (max)	5500 RPM
Cutting depth (45º)	48 mm
Cutting depth (90º)	66 mm
Input power	1500 W
Power source	AC
AC input voltage	230 V
AC input frequency	50 Hz
Saw blade included	-

Weight and Dimensions

Depth	370 mm
Width	275 mm
Height	270 mm
Weight	5160 g
Blade thickness	2.8 mm
