33 | Avoset Quick Guide
Low Battery
2. Press and hold the key to turn off the pump
1. Press
to pause the
infusion
S N A400 1 1 198
SW ER.
1.02
V
+
–
START
BOLUS
PRIME
PAUSE
ON/OFF
GO
RUN
ALARM
+
–
START
BOLUS
PRIME
PAUSE
ON/OFF
GO
RUN
ALARM
3. Press down the
battery cover latch to
open it
4. Remove each
battery starting with
the positive (+) ends
6. Close the battery cover.
To resume infusion, turn the
pump on and select RESUME
multi-function button (see
page 19).
5. Insert 3 AA (1.5V) batteries according the diagram
in the battery compartment.
Slide the negative (-) end rst, compress the spring
and snap the positive (+) end into place
The batteries are about to deplet in 30 minutes for the current running infusion.
+
–
START
BOLUS
PRIME
PAUSE
ON/OFF
GO
RUN
ALARM
BEEP
LOW BATTERY
DISMISSMUTE
LOW BATTERY
DISMISSMUTE
Infusion is saved when batteries are removed,
and can be resumed later.
