Eizo FlexScan EV2450 User Manual

- 36 -
Chapter 4 Administrator Settings
Function Setting Range Description Note
USB Power Save On
Off
This product can disable USB communication with a PC when
the monitor enters power saving mode or when the monitor is
turned off. Disabling USB communication can reduce power
consumption in power saving mode and when the monitor is
turned off.
When this function is set to “Off”, USB connections can be left
enabled even when the monitor enters power saving mode or
when the monitor is turned off.
• When this function is set to “On”, make sure to
complete any communication between connected
USB devices and the PC before turning off the
monitor. If storage devices, such as a USB ash
drive, are connected, turning off the monitor before
completing communication may result in data loss
or damage to storage devices.
• When this function is set to “On”, the monitor
cannot be controlled using software, such as
“ScreenManager Pro”, when the monitor is in
power saving mode or when the monitor is turned
off.
• When this function is set to “Off”, power
consumption is higher in power saving mode and
when the monitor is turned off.
On-Screen Logo On
Off
When the monitor is turned on, the EIZO logo appears on the
screen.
When this function is set to “Off”, the EIZO logo does not appear.
-
Key Lock On
Off
In order to prevent changes to settings, the operation switches on
the front of the monitor can be locked.
• The following operation is available even if the
switches are locked:
- Turning the monitor on or off with the Power
switch
Compatibility Mode On
Off
Depending on the PC and graphics board, the input signal may
not be detected and the monitor may not recover from power
saving mode. If this happens, set this function to “On”.
-

Eizo FlexScan EV2450 Specifications

General

3D	No
Pixel pitch	0.2745 x 0.2745 mm
Aspect ratio	16:9
Screen shape	Flat
Display diagonal	23.8 \
Separate H/V sync	Yes
Display technology	LED
Vertical scan range	55 - 76 Hz
Horizontal scan range	31 - 81 kHz
Viewable size, vertical	296.4 mm
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	527 mm
Digital vertical frequency	59 - 61 Hz
Digital horizontal frequency	31 - 68 kHz
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	720 x 400, 1280 x 1024 (SXGA), 1280 x 768 (WXGA), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 640 x 480 (VGA), 800 x 600 (SVGA)
USB hub version	3.2 Gen 1 (3.1 Gen 1)
Headphone connectivity	3.5 mm
USB upstream port type	USB Type-B
USB Type-A downstream ports quantity	2
RMS rated power	2 W
Certification	TCO Displays 6.0, EPEAT Gold (US), TUV/Ergonomics (including ISO9241-307), TUV/GS, RCM, CE, CB, cTUVus, FCC-B, Canadian ICES-003-B, TUV/S, VCCI-B, EPA Energy Star, WEEE, China RoHS, CCC, GOST-R
Product color	Gray
Market positioning	-
Compliance industry standards	RoHS
Pivot angle	-90 - 90 °
Tilt angle range	-5 - 35 °
Number of OSD languages	9
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DEU, ENG, ESP, FRE, ITA, JPN, SWE
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	47 W
Power consumption (standby)	0.3 W
Power consumption (typical)	15.6 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	EPEAT Gold, ENERGY STAR
Cables included	AC, DisplayPort, USB
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	233 mm
Height (with stand)	473.5 mm
Weight (with stand)	6200 g
Depth (without stand)	47.9 mm
Width (without stand)	537.6 mm
Height (without stand)	317.6 mm
Weight (without stand)	3800 g
