Eizo FlexScan EV2450 User Manual

- 54 -
Chapter 6 Reference
Power Input 100 - 120 VAC ±10 %, 50 / 60 Hz 0.85 A
200 - 240 VAC ±10 %, 50 / 60 Hz 0.55 A
Maximum Power Consumption 49 W or less
Power Save Mode 0.3 W or less (no USB device connected, default settings)
Standby Mode 0.3 W or less (no USB device connected, default settings)
Physical
Specications
Dimensions Min. height:
Max. height:
530.8 mm × 347.0 mm × 286.4 mm (W × H × D) (Tilt: 35˚)
530.8 mm × 488.2 mm × 233.0 mm (W × H × D) (Tilt: 0˚)
Dimensions (Without Stand) 530.8 mm × 347.2 mm × 47.9 mm (W × H × D)
Net Weight Approx. 6.5 kg
Net Weight (Without Stand) Approx. 4.1 kg
Height Adjustment Range 114.7 mm (Tilt: 35˚) / 131 mm (Tilt: 0˚)
Tilt Up 35˚, down 5˚
Swivel 344˚
Vertical Rotation Left 90˚, right 90˚
Operating
Environmental
Requirements
Temperature 5˚C to 35˚C (41˚F to 95˚F)
Humidity 20% to 80% R.H. (no condensation)
Air Pressure 540 hPa to 1060 hPa
Transportation/
Storage
Environmental
Requirements
Temperature -20˚C to 60˚C (-4˚F to 140˚F)
Humidity 10% to 90% R.H. (no condensation)
Air Pressure 200 hPa to 1060 hPa

Eizo FlexScan EV2450 Specifications

General

3D	No
Pixel pitch	0.2745 x 0.2745 mm
Aspect ratio	16:9
Screen shape	Flat
Display diagonal	23.8 \
Separate H/V sync	Yes
Display technology	LED
Vertical scan range	55 - 76 Hz
Horizontal scan range	31 - 81 kHz
Viewable size, vertical	296.4 mm
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	527 mm
Digital vertical frequency	59 - 61 Hz
Digital horizontal frequency	31 - 68 kHz
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	720 x 400, 1280 x 1024 (SXGA), 1280 x 768 (WXGA), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 640 x 480 (VGA), 800 x 600 (SVGA)
USB hub version	3.2 Gen 1 (3.1 Gen 1)
Headphone connectivity	3.5 mm
USB upstream port type	USB Type-B
USB Type-A downstream ports quantity	2
RMS rated power	2 W
Certification	TCO Displays 6.0, EPEAT Gold (US), TUV/Ergonomics (including ISO9241-307), TUV/GS, RCM, CE, CB, cTUVus, FCC-B, Canadian ICES-003-B, TUV/S, VCCI-B, EPA Energy Star, WEEE, China RoHS, CCC, GOST-R
Product color	Gray
Market positioning	-
Compliance industry standards	RoHS
Pivot angle	-90 - 90 °
Tilt angle range	-5 - 35 °
Number of OSD languages	9
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DEU, ENG, ESP, FRE, ITA, JPN, SWE
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	47 W
Power consumption (standby)	0.3 W
Power consumption (typical)	15.6 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	EPEAT Gold, ENERGY STAR
Cables included	AC, DisplayPort, USB
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	233 mm
Height (with stand)	473.5 mm
Weight (with stand)	6200 g
Depth (without stand)	47.9 mm
Width (without stand)	537.6 mm
Height (without stand)	317.6 mm
Weight (without stand)	3800 g
