- 62 -
Chapter 7 Glossary
Resolution
The LCD panel consists of numerous pixels of specied size, which are illuminated to form images. This monitor consists of horizontal 1920 pixels and
1080 vertical pixels (EV2450), or horizontal 1920 pixels and 1200 vertical pixels (EV2455). At a resolution of 1920 × 1080 (EV2450) or 1920 × 1200
(EV2455), all pixels are illuminated as a full screen (1:1).
sRGB (Standard RGB)
International standard for color reproduction and color space among peripheral devices (such as monitors, printers, digital cameras, scanners). As a form
of simple color matching for the Internet, colors can be displayed using tones close to those of the transmission and reception devices.
Temperature
Color temperature is a method to measure the white color tone, generally indicated in degrees Kelvin. The screen becomes reddish at a low temperature,
and bluish at a high temperature, like the ame temperature.
5000 K: Slightly reddish white
6500 K: White referred to as daylight-balanced color
9300 K: Slightly bluish white
TMDS (Transition Minimized Differential Signaling)
A signal transmission system for digital interface.

Table of Contents

Other manuals for Eizo FlexScan EV2450

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Eizo FlexScan EV2450 and is the answer not in the manual?

Eizo FlexScan EV2450 Specifications

General IconGeneral
3DNo
Pixel pitch0.2745 x 0.2745 mm
Aspect ratio16:9
Screen shapeFlat
Display diagonal23.8 \
Separate H/V syncYes
Display technologyLED
Vertical scan range55 - 76 Hz
Horizontal scan range31 - 81 kHz
Viewable size, vertical296.4 mm
Contrast ratio (typical)1000:1
Display number of colors16.78 million colors
Viewable size, horizontal527 mm
Digital vertical frequency59 - 61 Hz
Digital horizontal frequency31 - 68 kHz
Display brightness (typical)250 cd/m²
Supported graphics resolutions720 x 400, 1280 x 1024 (SXGA), 1280 x 768 (WXGA), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 640 x 480 (VGA), 800 x 600 (SVGA)
USB hub version3.2 Gen 1 (3.1 Gen 1)
Headphone connectivity3.5 mm
USB upstream port typeUSB Type-B
USB Type-A downstream ports quantity2
RMS rated power2 W
CertificationTCO Displays 6.0, EPEAT Gold (US), TUV/Ergonomics (including ISO9241-307), TUV/GS, RCM, CE, CB, cTUVus, FCC-B, Canadian ICES-003-B, TUV/S, VCCI-B, EPA Energy Star, WEEE, China RoHS, CCC, GOST-R
Product colorGray
Market positioning-
Compliance industry standardsRoHS
Pivot angle-90 - 90 °
Tilt angle range-5 - 35 °
Number of OSD languages9
Panel mounting interface100 x 100 mm
On Screen Display (OSD) languagesCHI (SIMPL), CHI (TR), DEU, ENG, ESP, FRE, ITA, JPN, SWE
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Energy efficiency scaleA to G
Power consumption (max)47 W
Power consumption (standby)0.3 W
Power consumption (typical)15.6 W
Operating temperature (T-T)5 - 35 °C
Operating relative humidity (H-H)20 - 80 %
Sustainability certificatesEPEAT Gold, ENERGY STAR
Cables includedAC, DisplayPort, USB
Harmonized System (HS) code85285210
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)233 mm
Height (with stand)473.5 mm
Weight (with stand)6200 g
Depth (without stand)47.9 mm
Width (without stand)537.6 mm
Height (without stand)317.6 mm
Weight (without stand)3800 g
