1 | Introduction
10
1.2.2 Rear
1. Handle This handle is used for transportation.
2. Security lock slot Complies with Kensington’s MicroSaver security system.
3. Lock button Use this button to remove the monitor from the stand.
4. Headphone jack Connects to headphones.
5. USB-A connector
(downstream)
Connects to a peripheral USB device (see Using the USB Hub
Function [}38]).
6. Cable holder Holds the monitor cables.
7. Stand
*1
Adjusts the height and angle (tilt and swivel) of the monitor. The
monitor can also be rotated vertically.
8. Main power switch Turns the main power on or off.
: On : Off
9. Power connector Connects the power cord.
10. HDMI connector Connects to a PC with HDMI output.
11. DisplayPort connector Connects to a PC with DisplayPort output.
12. USB-C connector
(upstream)
Connects to a PC with USB-C output. This also transmits the USB
signal that is necessary for using software that requires USB
connection.
*1
An optional arm (or optional stand) can be attached by removing the stand section.
