6 | Attaching/Removing the Stand
36
6.3 Attaching the Original Stand
1. Lay the LCD monitor on a soft cloth spread over a stable and flat surface with the LCD
panel surface facing down.
2. Remove the fixing screws on the optional arm (or optional stand), and detach the
optional arm (or optional stand).
3. Attach the original stand.
Insert the four tabs on the stand into the four holes on the back panel (1), and slide the
stand towards the upper portion of the monitor (2). The stand clicks when it is attached
correctly. Check that the stand is properly attached by pushing it side to side and back
to front.
