Attaching/Removing the Stand | 6
35
Attention
• When attaching an arm or stand, follow the instructions of the respective User’s Manual.
• When using another manufacturer’s arm or stand, confirm the following in advance and select
one conforming to the VESA standard:
– Clearance between screw holes: 100 mm x 100 mm
– VESA mount of the arm or stand, external dimensions: 122 mm x 122 mm or less
– Plate thickness: 2.6 mm
– Strong enough to support weight of the monitor unit (excluding the stand) and attachments
such as cables
• Connect the cables after attaching an arm or stand.
• Do not move the removed stand up and down. Doing so may result in injury or device damage.
• The monitor, arm, and stand are heavy. Dropping them may result in injury or equipment
damage.
• Check periodically that the screws are tight enough. If the screws are not tight enough, the
monitor may come unattached. This may be the cause of injury or damage.
1. Attach the arm or stand to the monitor.
For installation, use commercially available screws that meet the following conditions:
– Nominal diameter: M4
– Length: Between 7.6 mm and 10.6 mm (if using washers, add the washer thickness)
To Next Page
