Eizo FlexScan EV2795 User Manual

●
Rear
17
1613 14
12
11
10
9
8
7
6
15
18 19 20
6. Handle This handle is used for transportation.
7. Security lock slot Complies with Kensington’s MicroSaver security system.
8. Lock button Use this button to remove the monitor from the stand.
9. Headphone jack Connects to headphones.
10. USB Type-A
connector
(downstream)
Connects to a peripheral USB device (page 36).
11. Cable cover Holds the monitor cables.
12. Stand
*1
Adjusts the height and angle (tilt and swivel) of the monitor.
13. Main power switch
Turns the main power on or o󰀨.
: On, : O󰀨
14. Power connector Connects the power cord.
15. LAN port (RJ-45)
When using a network connection with the docking station function (page 36),
this connects to a modem or router with a LAN cable.
16. HDMI connector
Connects to a PC with HDMI output.
17. DisplayPort
connector
Connects to a PC with DisplayPort output.
18. USB Type-B
connector
(upstream)
Connect the USB cable when using software that requires USB connection or when
using the docking station function (page 36).
19. USB Type-C
connector
(upstream)
Connects to a PC with USB Type-C output. This also transmits the USB signal that
is necessary for using software that requires USB connection or when using the
docking station function (page 36).
20. USB Type-C
connector
(downstream)
When connecting in a daisy chain connection, this connects to the USB Type-C
upstream connectors of the other monitors in the conguration.
*1 An optional arm (or optional stand) can be attached by removing the stand section.
10
Chapter 1 Introduction

Eizo FlexScan EV2795 Specifications

General

Energy efficiency scale	A to G
