When two PCs are connected to one monitor, you can link the input signals with the USB ports to use a
USB device connected to the monitor from both PCs by switching between them. For details, refer to
“KVM” (page 27).
●
Connection Procedure (Using a USB Device from Two PCs by
Switching between Them)
USB Type-A
Downstream
USB Type-C
Downstream
CC200SS-5A
or
CC200SSW-5A
USB cable
(USB Type-C - USB Type-C)
(Included)
USB 3.0 cable
(USB Type-B - USB Type-A)
(Commercially available
product)
USB Type-B
Upstream
USB Type-C
Upstream
USB Type-CUSB Type-A
Note
• You can select the input signal to display using the operation switch on the front of the monitor. For details, see
“2-2. Switching Input Signals” (page 14).
• This product provides a function that automatically recognizes the connector through which PC signals are input,
and displays images on the screen accordingly. For details, see “Auto Input Detection” (page 26).
38
Chapter 7 Reference
