TECNOEKA Srl ___________________________________________________________ operating and instruction manual
page 28 _____________________________________________________________________________________________
KEY
C1
START OF COOKING
C2
COOKING CORRECTLY ENDED
C3
COOKING INTERRUPTED WITH START/STOP KEY OR DUE TO AN ALARM
AL1
ALARM: OPEN DOOR
AL2
ALARM: THE CORE PROBE HAS BROKEN DOWN DURING COOKING
AL3
ALARM: THE TEMPERATURE PROBE IS FAULTY
AL4
ALARM: MOTOR
AL5
ALARM: SAFETY THERMOSTAT
AL9
ALARM: RESISTORS ARE NOT CONNECTED
R
RECIPE NAME
R: MAN
MANUALLY SET RECIPE
F0
TYPE OF MANUAL RECIPE
F1
FIRST COURSES
F2
SECOND COURSES
F3
FISH
F4
GAME
F5
BREAD
F6
VEGETABLES
F7
DESSERTS
F8
EXTRA
T1
TEMPERATURE DETECTED IN THE COOKING CHAMBER
T2
TEMPERATURE DETECTED BY THE CORE PROBE
D1
THE DOOR WAS OPENED DURING COOKING
D2
THE DOOR WAS CLOSED DURING COOKING
POSSIBLE ERRORS OF “HACCP” FUNCTION
Type of error
Cause of the error
Corrective action
Er. 1 IMPOSSIBLE
TO SAVE “HACCP”
- The “USB pen drive” was removed
- Insert the “USB pen drive” to
save the data of the next
cooking cycle
Er. 2 IMPOSSIBLE
TO SAVE “HACCP”
- The “USB pen drive” was removed
and a drive was inserted not in
“FAT” format
- Insert the “USB pen drive” (max
2GB) in “FAT” format to save
the data of the next cooking
cycle
Er. 3 IMPOSSIBLE
TO SAVE “HACCP”
- Incorrect “USB pen drive” format
- The “USB pen drive” must be in
“FAT” (max 2GB) format to be
able to save the following
cooking cycle data
