- 4 - - 5 -
Sealing Gasket
EK-Quantum
Kinetic TBE 120/160 VTX PWM
VTX Pump
M4 VTX Screw
Vibration Damper
EK-Quantum Kinetic TBE VTX can be used in any mounting
configuration (position) apart from being mounted upside-down.
Mounting the pump upside-down may result in the pump
running dry and eventually lead to its failure!
INSTALLING THE ASSEMBLY
EK-Quantum
Kinetic TBE VTX
Pump Bracket
