ELAC CONCENTRO - Technical Specifications

Höhe 1680 mm mit Spikes 1450 mm mit Spikes
Breite 460 mm mit Fuß 406 mm mit Fuß
Tiefe 610 mm mit Fuß 535 mm mit Fuß
Gewicht 152 kg 90 kg
Bauart 4-Wege, Bassrefl ex 3-Wege, Bassrefl ex
Tieftöner 4 x 250 AS mm Ø, Konus 4 x 220 AS mm Ø,
Konus
Tiefmitteltöner 1 x 220 AS-XR mm Ø, Konus –
Mitteltöner 1 x 70 | 140 mm Ø, AS-XR
Ringstrahler
1 x 70 | 140 mm Ø, AS-XR
Ringstrahler
Hochtöner JET 5 Core, modifi ziert JET 5 Core, modifi ziert
Trennfrequenzen der Weiche 120 | 360 | 2700 Hz 180 | 2700 Hz
Nennbelastbarkeit 400 W 300 W
Minimalimpedanz 3,0Ω bei 620 Hz 2,8Ω bei 380 Hz
Impulsbelastbarkeit 600 W 400 W
Übertragungsbereich
(n. IEC 268-5)
18 – 50000 Hz 24 – 50000 Hz
Empfi ndlichkeit 90 dB / 2,83 V/m 88 dB / 2,83 V/m
Geeignete Verstärker von ... bis 4 – 8 Ω 4 – 8 Ω
Nennimpedanz 4 Ω 4 Ω
Empf. Verstärkerleistung.an
o.a. Nennimpedanz 80 – 600 W/Kanal 80 – 600 W/Kanal
Farbausführungen Schwarz Lack Hochglanz,
Weiss Lack Hochglanz
Schwarz Lack Hochglanz,
Weiss Lack Hochglanz
Zubehör Bi-Wiring-Brückenset,
Handschuhe, Rollwagen,
Werkzeugset
Bi-Wiring-Brückenset,
Handschuhe, Werkzeugset
CONCENTRO MCONCENTRO
TECHNICAL SPECIFICATIONS
Height 1680 mm with spikes 1450 mm with spikes
Width 460 mm with base 460 mm with base
Depth 610 mm with base 535 mm with base
Weight 152 kg 90 kg
Type 4-Way, bass refl ex 3-Way, bass refl ex
Woofer 4 x 250 mm Ø AS cone 4 x 220 mm Ø AS, cone
Low-Midrange 1 x 220 mm Ø AS XR cone –
High-Midrange 1 x 70 / 140 mm Ø, AS XR ring
radiator
1 x 70 / 140 mm Ø, AS XR
ring radiator
Tweeter JET 5 Core, modifi ed JET 5 Core, modifi ed
Crossover frequency 120 | 360 | 2700 Hz 180 | 2700 Hz
Nominal power handling 400 W 300 W
Minimal impedance 3,0Ω at 620 Hz 2,8Ω at 380 Hz
Peak power handling 600 W 400 W
Frequency range (IEC 268-5) 18 – 50000 Hz 24 – 50000 Hz
Sensitivity 90 dB/2,83 V/m 88 dB/2,83 V/m
Suitable for amplifi ers from … to 4 – 8 Ω 4 – 8 Ω
Nominal impedance 4 Ω 4 Ω
Recommended amplifi er power 80 - 600 W/channel 80 - 600 W/channel
Finishes Black High Gloss,
White High Gloss
Black High Gloss,
White High Gloss
Accessories included
in delivery
bi-wiring set, gloves, tool set,
trolley
bi-wiring set, gloves, tool set
