ELAC MicroSUB 2010 BT - Brief Description of Controls and Connections

Brief description of controls and connections 25
1 cable terminals for left satellite speaker
2 cable terminals for right satellite speaker
3 RCA sockets L/R (e.g. for connection of CD-Player)
4 input socket for external power supply (16V-, max. 100W)
5 LED for operating state
6 power mode selector
7 subwoofer level control
8 master volume control
9 crossover frequency selector
10 LED for Bluetooth® activity
11 Bluetooth receiving aerial
